NETGEAR ProSafe GS108 User Manual

2-1
v1.0, May 2007
Chapter 2
Introduction to the Web Browser Interface
This section introduces the browser interface that enables you to configure and manage your
NETGEAR GS108T Gigabit Smart Switch. Your GS108T Smart Switch provides a built-in
browser interface that enables you to configure and manage it remotely using a standard Web
browser such as Microsoft Internet Explorer or Netscape Navigator. Online Help is also provided
for many of the basic functions and features of the switch.
This section introduces the areas of the browser interface and includes the following headings:
• “Logging Into the NETGEAR Home Page”
• “Other Features of the Browser Interface”
Logging Into the NETGEAR Home Page
Begin your overview of the GS108T Smart Switch browser interface by logging in:
1. Start the application, either through the SmartWizard Discovery utility or directly by entering
the switch’s IP address, as described in Chapter 1, “Getting Started with Switch Management”.
2. Press Enter. The Login page appears as shown below.

NETGEAR ProSafe GS108 Specifications

General

MAC address table	8000 entries
Maximum data transfer rate	1 Gbit/s
Full duplex	Yes
Networking standards	IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Latency	20 μs
Dimensions (WxDxH)	235.5 x 100.8 x 27 mm
Power requirements	5 V @ 2.8 A DC
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet
Switch type	Unmanaged
Basic switching RJ-45 Ethernet ports quantity	8
Noise level	0 dB
Mean time between failures (MTBF)	91.500 h
Power consumption (typical)	14 W
Safety	UL (UL 1950), CUL, C-Tick
LED indicators	Link, Power
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	760 g
