NETGEAR ProSafe GS108 User Manual

GS108T Smart Switch Software Administration Manual
Managing System Settings 3-9
v1.0, May 2007
Example: If RADIUS, Local is selected, the RADIUS server is used to authenticate a
user. If the RADIUS server is unavailable, or there is no RADIUS server on the network,
then authentication is done locally.
b. Click Apply to update the authentication procedure.
3. Specify the new password:
a. Old Password: Enter the current password to access the switch.
b. New Password: Enter the new password to access the switch. The maximum length of
password is 15 characters. All printable characters are allowed.
c. Confirm New Password: Re-enter the new password.
d. Click Apply to update the password.
RADIUS Server
Click RADIUS Server in the upper part of the blue navigation panel to expand the item to
Password and RADIUS. Then click RADIUS (if necessary) to expand the Radius submenu to
Server.
The RADIUS server is Remote Authentication Dial-In User Service (RADIUS) defined in
RFC2865. The server is used by ISPs to authenticate a username and password before authorizing
use of the network. You can configure both a primary server and a backup server.
1. Click Server in the blue navigation panel. A screen similar to that shown below appears.
Note: It is good practice to select a password more than eight characters long and
is a combination of numbers and letters. Names and simple words can be
easy to guess. If you forget your password, you can always press the
Factory Reset button on the switch and the password will return to the
default value of password.

NETGEAR ProSafe GS108 Specifications

General

MAC address table	8000 entries
Maximum data transfer rate	1 Gbit/s
Full duplex	Yes
Networking standards	IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Latency	20 μs
Dimensions (WxDxH)	235.5 x 100.8 x 27 mm
Power requirements	5 V @ 2.8 A DC
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet
Switch type	Unmanaged
Basic switching RJ-45 Ethernet ports quantity	8
Noise level	0 dB
Mean time between failures (MTBF)	91.500 h
Power consumption (typical)	14 W
Safety	UL (UL 1950), CUL, C-Tick
LED indicators	Link, Power
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	760 g
