GS108T Smart Switch Software Administration Manual
Configuring the Switch 4-9
v1.0, May 2007
VLAN
Click VLAN in the middle part of the blue navigation panel to expand the item to VLAN Group
Setting and Management VLAN.
VLAN Group Setting
Possible VLAN group settings include IEEE 802.1Q VLAN and port-based VLAN.
IEEE 802.1Q VLAN
The settings on the IEEE 802.1Q VLAN page control the VLAN membership of each port for
transmitting packets. Also, these settings determine if transmitted packets from each port are
tagged with the VLAN ID and other information. The switch supports 64 Tag-based VLANs.
By default, every port is a member of VLAN 1 and so they have a Port VLAN ID (PVID) of 1.
Click VLAN Group Setting in the blue navigation panel. A screen similar to that shown below
appears when IEEE 802.1Q VLAN is selected for the VLAN group setting.
.
You can add, change, or delete VLANs and ports.
Figure 4-30

NETGEAR ProSafe GS108 Specifications

General

MAC address table	8000 entries
Maximum data transfer rate	1 Gbit/s
Full duplex	Yes
Networking standards	IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Latency	20 μs
Dimensions (WxDxH)	235.5 x 100.8 x 27 mm
Power requirements	5 V @ 2.8 A DC
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet
Switch type	Unmanaged
Basic switching RJ-45 Ethernet ports quantity	8
Noise level	0 dB
Mean time between failures (MTBF)	91.500 h
Power consumption (typical)	14 W
Safety	UL (UL 1950), CUL, C-Tick
LED indicators	Link, Power
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	760 g
