NETGEAR ProSafe GS108 User Manual

GS108T Smart Switch Software Administration Manual
Managing System Settings 3-15
v1.0, May 2007
4. When setting the date and time manually:
a. Date: Specify the date to which the switch is set in DD/MM/YYYY format.
b. Local Time: Specify the switch time in HH:MM:SS format.
5. When setting the date and time with the SNTP server:
a. NTP Server IP - 1: Specify the IP address of the primary NTP/SNTP Server for the
switch to use when synchronizing time.
b. NTP Server IP - 2: Specify the IP address of alternate NTP/SNTP Server for the switch to
use when synchronizing time.
6. Click Apply to update the time settings.
LLDP
Click LLDP (Link Layer Discovery Protocol) in the upper part of the blue navigation panel to
expand the item to Configuration, Statistics, Local Information, and MSAP Information.
LLDP Configuration
LLDP is a one way protocol.
• An LLDP agent can transmit information about the capabilities and current status of the switch
associated with its MSAP (MAC Service Access Point) identifier.
• The LLDP agent can also receive information about the capabilities and current status of the
switch associated with a remote MSAP identifier.
However, LLDP agents are not provided with any means of soliciting information from other
LLDP agents via this protocol.
Switch Settings
1. Click Configuration in the blue navigation panel. A screen similar to that shown below
appears.

NETGEAR ProSafe GS108 Specifications

General

MAC address table	8000 entries
Maximum data transfer rate	1 Gbit/s
Full duplex	Yes
Networking standards	IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Latency	20 μs
Dimensions (WxDxH)	235.5 x 100.8 x 27 mm
Power requirements	5 V @ 2.8 A DC
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet
Switch type	Unmanaged
Basic switching RJ-45 Ethernet ports quantity	8
Noise level	0 dB
Mean time between failures (MTBF)	91.500 h
Power consumption (typical)	14 W
Safety	UL (UL 1950), CUL, C-Tick
LED indicators	Link, Power
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	760 g
