NETGEAR ProSafe GS108 User Manual

5-1
v1.0, May 2007
Chapter 5
Managing Firmware and Reset Options
The Firmware selections on the navigation menu enable you to manage the switch’s firmware and
configuration files and reset the switch:
• Upload or download the firmware and configuration files between a TFTP Server or HTTP
Host and the switch so that you can back up and either restore or update the switch.
• Reset the switch to its factory default values.
• Restart the switch with its current configuration.
The section includes this information under the following headings:
• “File Management”
• “Factory Reset”
• “Reset”
File Management
Click File Management in the lower part of the blue navigation panel to expand the item to File
Upload and File Download.
File Upload
File Upload enables you to back up the current firmware and configuration switch files to a TFTP
Server or HTTP Host.
1. Click File Upload in the blue navigation panel. A screen similar to that shown below appears.

NETGEAR ProSafe GS108 Specifications

General

MAC address table	8000 entries
Maximum data transfer rate	1 Gbit/s
Full duplex	Yes
Networking standards	IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Latency	20 μs
Dimensions (WxDxH)	235.5 x 100.8 x 27 mm
Power requirements	5 V @ 2.8 A DC
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet
Switch type	Unmanaged
Basic switching RJ-45 Ethernet ports quantity	8
Noise level	0 dB
Mean time between failures (MTBF)	91.500 h
Power consumption (typical)	14 W
Safety	UL (UL 1950), CUL, C-Tick
LED indicators	Link, Power
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	760 g
