NETGEAR ProSafe GS108 User Manual

GS108T Smart Switch Software Administration Manual
Configuring the Switch 4-17
v1.0, May 2007
.
• If a user sets VLAN 0, all created VLANs are allowed.
• When the system works on the port-based VLAN mode, the VLAN value is always set to 0.
Link Aggregation
Two types of link aggregation are supported:
• Static Trunking: the ports are grouped manually.
• Link Aggregation Control Protocol (LACP): part of IEEE specification (802.3ad) that
allows several physical ports to be bundled together to form a single logical channel. Link
aggregation allows one or more links to be aggregated together to form a Link Aggregation
Group, such that a MAC Client can treat the Link Aggregation Group as if it were a single
link. Link aggregation can be used on 10-Mbps, 100-Mbps, or 1000-Mbps Ethernet full duplex
ports.
Example: A network administrator could combine a group of five 100-Mbps ports into a logical
link that will function as a single 500-Mbps port (the actual throughput however will be less than
the sum total of the links).
Figure 4-38

NETGEAR ProSafe GS108 Specifications

General

MAC address table	8000 entries
Maximum data transfer rate	1 Gbit/s
Full duplex	Yes
Networking standards	IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Latency	20 μs
Dimensions (WxDxH)	235.5 x 100.8 x 27 mm
Power requirements	5 V @ 2.8 A DC
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet
Switch type	Unmanaged
Basic switching RJ-45 Ethernet ports quantity	8
Noise level	0 dB
Mean time between failures (MTBF)	91.500 h
Power consumption (typical)	14 W
Safety	UL (UL 1950), CUL, C-Tick
LED indicators	Link, Power
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	760 g
