GS108T Smart Switch Software Administration Manual
4-22 Configuring the Switch
v1.0, May 2007
Advanced
Click Advanced in the middle part of the blue navigation panel to expand the item to Jumbo
Frame, Rate Limiting, Storm Control, Spanning Tree, and SNMP.
Jumbo Frame
The Jumbo Frame page allows you to enable or disable the Jumbo Frame support. The default
frame size is 1518 bytes. When jumbo frame support is enabled the frame size may vary from
1,518 to 9,728 bytes.
1. Click Jumbo Frame in the blue navigation panel. A screen similar to that shown below
appears.
.
2. Click Disable or Enable.
3. Click Apply.
Rate Limiting
Rate Control determines the bandwidth of ingress and egress traffic for a specific port.
Figure 4-42

NETGEAR ProSafe GS108 Specifications

General

MAC address table	8000 entries
Maximum data transfer rate	1 Gbit/s
Full duplex	Yes
Networking standards	IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Latency	20 μs
Dimensions (WxDxH)	235.5 x 100.8 x 27 mm
Power requirements	5 V @ 2.8 A DC
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet
Switch type	Unmanaged
Basic switching RJ-45 Ethernet ports quantity	8
Noise level	0 dB
Mean time between failures (MTBF)	91.500 h
Power consumption (typical)	14 W
Safety	UL (UL 1950), CUL, C-Tick
LED indicators	Link, Power
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	760 g
