GS108T Smart Switch Software Administration Manual
Managing System Settings 3-11
v1.0, May 2007
• 802.1x: The Radius server is used for dot1x authentication.
• All: The Radius server is used for both logging in and dot1x authentication.
3. Backup Server: Define the RADIUS Backup Server authentication fields in a similar manner.
4. Click Apply to update the RADIUS servers.
MAC Address Table
Click MAC Address Table in the upper part of the blue navigation panel to expand the item to
Static Address and Dynamic Address.
Static Address
1. Click Static Address in the blue navigation panel. A screen similar to that shown below
appears.
.
2. Add or remove static addresses on the Static Addresses list.
Adding a static address to the Static Addresses list
Figure 3-10

NETGEAR ProSafe GS108 Specifications

General

MAC address table	8000 entries
Maximum data transfer rate	1 Gbit/s
Full duplex	Yes
Networking standards	IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Latency	20 μs
Dimensions (WxDxH)	235.5 x 100.8 x 27 mm
Power requirements	5 V @ 2.8 A DC
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet
Switch type	Unmanaged
Basic switching RJ-45 Ethernet ports quantity	8
Noise level	0 dB
Mean time between failures (MTBF)	91.500 h
Power consumption (typical)	14 W
Safety	UL (UL 1950), CUL, C-Tick
LED indicators	Link, Power
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	760 g
