GS108T Smart Switch Software Administration Manual
5-2 Managing Firmware and Reset Options
v1.0, May 2007
.
2. Click Firmware Upload or Configuration Upload to select the type of file for upload.
3. Click TFTP or HTTP to select the upload mode.
If the TFTP mode is selected:
a. Enter the IP Address of the TFTP Server.
b. Enter the name of the firmware or configuration destination file in the TFTP server.
If the HTTP mode is selected:
a. Enter the name of the firmware or configuration destination file in the HTTP Host.
4. Click Apply to start the upload.
Figure 5-59

NETGEAR ProSafe GS108 Specifications

General

MAC address table	8000 entries
Maximum data transfer rate	1 Gbit/s
Full duplex	Yes
Networking standards	IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Latency	20 μs
Dimensions (WxDxH)	235.5 x 100.8 x 27 mm
Power requirements	5 V @ 2.8 A DC
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet
Switch type	Unmanaged
Basic switching RJ-45 Ethernet ports quantity	8
Noise level	0 dB
Mean time between failures (MTBF)	91.500 h
Power consumption (typical)	14 W
Safety	UL (UL 1950), CUL, C-Tick
LED indicators	Link, Power
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	760 g
