NETGEAR ProSafe GS108 User Manual

GS108T Smart Switch Software Administration Manual
Configuring the Switch 4-35
v1.0, May 2007
.
2. The Port Authentication Page contains the following fields:
• ID: Displays a list of interfaces on which port-based authentication is enabled.
• User Name: Displays the supplicant user name.
• Admin Port Control: Displays the current port authorization state.
• ReAuthenticate Now: Forces reauthentication of all existing clients.
• Enable Periodic Reauthentication: Permits immediate port reauthentication. The
possible field values are:
– Enable: Enables immediate port reauthentication. This is the default value.
– Disable: Disables port reauthentication.
• Reauthentication Period: Displays the time span (in seconds) in which the selected port
is reauthenticated. The field default is 3,600 seconds.
• Authenticator State: Displays the current authenticator state.
• Quiet Period: Displays the number of seconds that the device remains in the quiet state
following a failed authentication exchange. The possible field range is 0-65,535. The field
default is 60 seconds.
Figure 4-53

NETGEAR ProSafe GS108 Specifications

General

MAC address table	8000 entries
Maximum data transfer rate	1 Gbit/s
Full duplex	Yes
Networking standards	IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Latency	20 μs
Dimensions (WxDxH)	235.5 x 100.8 x 27 mm
Power requirements	5 V @ 2.8 A DC
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet
Switch type	Unmanaged
Basic switching RJ-45 Ethernet ports quantity	8
Noise level	0 dB
Mean time between failures (MTBF)	91.500 h
Power consumption (typical)	14 W
Safety	UL (UL 1950), CUL, C-Tick
LED indicators	Link, Power
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	760 g
