Olivetti PR2 E - Page 10

Y100250-4x
9.2.11 ROLLER SUPPORT TRAY DISASSEMBLY/REASSEMBLY .......................... 14
9.2.12 SERVICES MOTOR DISASSEMBLY/REASSEMBLY..................................... 15
9.2.13 FEEDER PHOTOSENSORS DISASSEMBLY/REASSEMBLY ....................... 16
9.2.14 PRINT BAR DISASSEMBLY/REASSEMBLY.................................................. 19
9.2.15 MAIN BOARD DISASSEMBLY/REASSEMBLY .............................................. 20
9.2.16 POWRER SUPPLY ASSY DISASSEMBLY/REASSEMBLY ........................... 21
9.3 BASIC MACHINE OPTIONS DISASSEMBLY/REASSEMBLY........................ 22
9.3.1 HORIZONTAL MAGNETIC DEVICE/MICR DISASSEMBLY/REASSEMBLY . 22
9.3.2 HORIZONTAL MAGNETIC DEVICE/MICR MOTOR
DISASSEMBLY/REASSEMBLY ...................................................................... 23
9.3.3 HORIZONTAL MAGNETIC DEVICE/MICR HEAD ASSY
DISASSEMBLY/REASSEMBLY ...................................................................... 24
