Olivetti PR2 E - MAIN BOARD CONNECTOR PIN-OUTS

Service ManualY100250-4 6-3
6.2.3 CONNECTOR PIN-OUT
Provided below are the pinouts of the connectors on the PR2 E main board. Connector J33 is not
indicates since it is only present on the BAPR2E Cost Improvement version.
J15
(PRINTHEAD CONNECTOR)
1 TESTE
2 LEBCA
3 FOBCA
4 VCCTES
5 R0224
6 SPL(2)
7 R0422
8 SPL(4)
9 R0620
10 SPL(6)
11 R1214
12 SPL(12)
13 R0717
14 SPL(17)
15 R1113
16 SPL(13)
17 R1113
18 SPL(11)
19 R0519
20 SPL(5)
21 R0422
22 SPL(22)
23 R0123
24 SPL(23)
25 R0519
26 SPL(19)
J16
(PRINTHEAD CONNECTOR)
1 R0818
2 SPL(8)
3 R1016
4 SPL(10)
5 R1214
6 SPL(14)
7 R0818
8 SPL(18)
9 R1016
10 SPL(16)
11 R0915
12 SPL(15)
13 R0915
14 SPL(9)
15 R0717
16 SPL(7)
17 R0321
18 SPL(3)
19 R0123
20 SPL(1)
21 R0620
22 SPL(20)
23 R0224
24 SPL(24)
25 R0321
26 SPL(21)
J9
(TRANSPORT MOTOR)
1 FASEA
2 FASEB
3 FASEC
4 FASED
1 GND
2 P5CONS
3 LED3
4 LEDLOC
5 LED2
6 LED1
7 LEDON
8 TAS01
9 TALOC
10 TAS02
11 COPEN
12 GND
J3
(CONSOLE)
J18
(RS 232 INTERFACE)
1 PIU35
2 PIU35
3 GND
4 GND
5 GND
6 VCC
7 PIU12
8 MEN12
9 RESEO
J10
(POWER SUPPLY)
1 DCD1
2 RX01
3 TX01
4 DTR1
5 GND
6 DSR1
7 RTS1
8 CTS1
9 TERRSE
