Olivetti PR2 E - CONFIGURATION PARAMETERS AND MENUS

Service ManualY100250-4 4-3
4.3.3 CONFIGURATION PARAMETERS
This section provides the description and possible values of the printer's different set-up parameters.
The default value is indicated in bold.
4.3.3.1 CONFIGURATION MODE MENU PARAMETERS
DRAFT SPEED: NORMAL - HIGH Determines the Draft mode that can
activated via SW and by default.
LQ TYPE:
NLQ1 - NLQ2 - LQ2 Determines the LQ type that can be
activated via SW and by default
PAPER WIDTH:
FIRST LINE – PROGRAMMABLE Determines document position/width
measurement position.
BUZZER: N -
Y Activates/deactivates acoustic signaling
INTERFACE:
RS 232 (1) – OPTIONAL – DUAL The optional interfaces are:
- PARALLEL (DUAL-compatible)
- RS 232 (2) (DUAL-compatible)
- USB
(when) RS232C (1)
EMULATION:
OLIVETTI – IBM Interface default emulation
BAUD RATE:
9600 - 4800 - 2400 - 1200 Data transmissione/reception rate
BIT/CHAR: 7 - 8 7- or 8-bit data format.
PARITY:
NONE - ODD - EVEN Type of parity checking.
STOP BIT:
1 - 2 Number of stop bits
DSR: N -
Y Data Set Ready handled or not.
DCD N -
Y Data Carrier Detector handled or not.
