Service ManualY100250-4 7-3
7.3 LUBRICATION
Although machine lubrication is not scheduled throughout its entire life span, during each service call
you are expected to check the lubrication of the differnet parts by referring to the lubrication points table
indicated below.
7.3.1 LUBRICATION POINTS ON THE BASIC MACHINE
DESCRIPTION CODE GREASE OIL
Printhead carriage slide shafts X
Carriage felt 473150E X
Ribbon feed gear assy X
Cam, in the contact area with: 473072X X
reed support pin, 473076T X
pressure bridge roller 473074Z X
Hole of the contact bushing between roller shaft 473170A X
and strap shaft 473171X X
Center pressure device in shaft contact area 473167T X
Bushings in the shaft contact area 473087P X
474953Y X
Motor gear, 473069C X
gear 473071W X
and cam teeth 473072X X
assembly gear 473174S X
473180V X
Pulley toothing 473017Q X
Hooking area leaf spring 473182K X
Ribbon feed rotation pin hole 473159B X
with support pin
Belt tightener pin with return pulley 473149H X
Alignment rollers shaft assy 474987K X
in torsion bar contact area 473091K
in conveyor assy guideway area 473186P
474951W
Rubber in the damper assembly hole 475871K X
Grease: Code 150337 M MAGNALUBE - E
Oil: Code 757283 C - FOMBLIN Y 06 oil (perfluorate polyether)
Supplier: Ausimont, a Montedison group company
