Service ManualY100250-4 1-3
1.2 GENERAL MACHINE CHARACTERISTICS
PRINTING MODULE Dot-matrix printhead with 24 diamond-shaped needles and overtemperature
protection
Printing capability: 1 original + 4 copies
Savings book handling features
PRINTING SPEED 86 cps @ 10 cpi in LQ
130 cps @ 10 cpi in NLQ
260 cps @ 10 cpi in DRAFT
350 cps @ 10 cpi in HSD
PRINT QUALITY H.S.D., DRAFT, N.L.Q., L.Q.
RIBBON CARTRIDGE Indelible fabric, with a life span of 3.5 M characters
PAPER FEED Front feeder with automatic document alignment.
If the magnetic device is present, the savings book must be aligned
manually. The machine will generate an error message.
PAPER SIZE 245 x 450 mm max.
70 x 65 mm min.
For more information refer to section 1.5.
CONSOLE Located on the printer cover, it has three buttons and five LEDs
EMULATIONS PR40+, PR2 E and IBM PP II, X24, SNI 4915, IBM 9068
INTERFACE Standard RS 232C serial with the possibility of installing the following
interface cards:
- RS 232C serial + USB
- Centronics parallel.
DIMENSIONS Width: 384 mm
Depth: 280 mm
Height: 195 mm
Weight: 10.5 Kg.
POWER CONSUMPTION Stand-by: < 15 W
During operation: 170 W max (worst case)
POWER SUPPLY Switching power supply:
100 to 130 VAC + 10%
200 to 240 VAC + 10%
