Y100250-46-12
6.6 CONSOLE
Fig. 6-6 Console
Fig. 6-7 Console Electrical Diagram
YELLOW LED 2
YELLOW LED 3
YELLOW LED 4
YELLOW LED 5
GREEN LED 1
BUTTON 1 BUTTON 2 BUTTON 3
YELLOW LED 5
YELLOW LED 4
YELLOW LED 3
YELLOW LED 2
GREEN LED 1
BUTTON 3
BUTTON 2
BUTTON 1
