Service ManualY100250-4 6-5
6.3 MAGNETIC OPTIONS CARD
The following magnetic options card can be installed on the BAPR2 main board:
- PR2MAGN, for the management of the horizontal magnetic device option
The option installed is controlled by the FW according to the parameters defined during machine setup.
6.3.1 CARD LOCATION AND IDENTIFICATION OF CONNECTORS
Fig. 6-2 Magnetic Options Card
J6
J3
J4
J5
J2
J1
