Olivetti PR2 E - Page 96

Y100250-46-4
J1
(ROLLERS MOTOR)
1 MR01A
2 MR01B
3 MR02A
4 MR02B
J6
(OPTIONS)
1 TXDS
2 SCKDS
J2
(PAPER FEED MOTOR)
1 TRF1A
2 TRF1B
3 TRF2A
4 TRF2B
1 FOCOM
2 VCCAL2
3 LECOM
4 LEAL3
5 LECOM
6 FOCOM
7 VCCAL4
8 FOAL3
9 VCC
10 FOAN2
11 LEAN2
12 LEAN1
13 FOAL1
14 FOAN1
15 LEAL1
J99
(FRONT PHOTOSENSORS)
J6
(OPTIONS)
1 ADSEL
2 FDCDM
J4
(CARRIAGE RESET)
1 VCC
2 VCC
3 GND
4 FAZCA
1 VCC
2 CKMOT
3 DACOM
4 FAZMA
5 PMAGN
6 VERMA
7 RESE0
8 F2FDA
9 PIU12
10 GND
J11
(OPTIONS)
1 MAC21
2 MAC20
3 MAC11
4 MAC10
5 MAPH2
6 MAPH1
7 PIU35
8 PIU35
9 GND
10 GND
J12
(OPTIONS)
J1
(INTERFACE)
1 GND
2 AD (14)
3 AD (10)
4 AD (12)
5 AD (8)
6 AD (6)
7 AD (4)
8 AD (2)
9 AD (0)
10 DA (6)
11 DA (4)
12 DA (2)
13 DA (0)
14 WAITO
15 READO
16 CKMOT
17 WROSP
18
19 BUSY1
20 ACK00
21 DACX (6)
22 DACX (4)
23 DACX (2)
24 RESUSB
25 SELRSUS
26 SUSPUSB
27 PESTR
28 RESEO
29 MEN12
30 PIU12
31 GND
AD (15)
AD (13)
AD (11)
AD (9)
AD (7)
AD (5)
AD (3)
AD (1)
DA (7)
DA (5)
DA (3)
DA (1)
ASTB0
WRITE
INTCX
RDOSP
CSEXP
GPI00T
STROB
DACX (7)
DACX (5)
DACX (3)
DACX (1)
IMPRA
ESTR2
ESTR1
GND
VCC
VCC
GND
PIU35
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
