205
Pulse Outputs Section 5-2
■ Setting Functions Using Instructions and PLC Setup
CPU Units with 10 I/O Points
CPU Units with 14 I/O Points
Address Default setting High-speed counter operation settings Origin searches
Word Bit Single-phase
(increment pulse input)
Two-phase (differential
phases x4, up/down, or
pulse/direction)
Origin searches
enabled for pulse
outputs 0
CIO 0 00 Normal input 0 Counter 0, increment input Counter 0, A phase, up, or
count input
---
01 Normal input 1 Counter 1, increment input Counter 0, B phase, down,
or direction input
---
02 Normal input 2 Counter 2, increment input Counter 1, A phase, up, or
count input
---
03 Normal input 3 Counter 3, increment input Counter 1, B phase, down,
or direction input
Pulse output 0: Origin
proximity input signal
04 Normal input 4 Counter 0, phase-Z/reset
input
Counter 0, phase-Z reset
input
---
05 Normal input 5 Counter 1, phase-Z reset
input
Counter 1, phase-Z reset
input
Pulse output 0: Origin
input signal
Input terminal
block
Default setting High-speed counter operation settings Origin searches
Word Bit Single-phase
(increment pulse input)
Two-phase (differential
phases x4, up/down, or
pulse/direction)
Origin searches
enabled for pulse
outputs 0 and 1
CIO 0 00 Normal input 0 High-speed counter 0
(Increment)
High-speed counter 0
(Phase A, Increment, or
Count input)
---
01 Normal input 1 High-speed counter 1
(Increment)
High-speed counter 0
(Phase B, Decrement, or
Direction input)
---
02 Normal input 2 High-speed counter 2
(Increment)
High-speed counter 1
(Phase A, Increment, or
Count input)
Pulse output 0:
Origin proximity input
signal
03 Normal input 3 High-speed counter 3
(Increment)
High-speed counter 1
(Phase B, Decrement, or
Direction input)
Pulse output 1:
Origin proximity input
signal
04 Normal input 4 High-speed counter 0
(Phase Z or reset input)
High-speed counter 0
(Phase Z or reset input)
---
05 Normal input 5 High-speed counter 1
(Phase Z or reset input)
High-speed counter 1
(Phase Z or reset input)
---
06 Normal input 6 High-speed counter 2
(Phase Z or reset input)
--- Pulse output 0:
Origin input signal
07 Normal input 7 High-speed counter 3
(Phase Z or reset input)
--- Pulse output 1:
Origin input signal
