243
Pulse Outputs Section 5-2
SET PULSES: PULS(886) PULS(886) is used to set the pulse output amount (number of output pulses)
for pulse outputs that are started later in the program using SPED(885) or
ACC(888) in independent mode.
SPEED OUTPUT:
SPED(885)
SPED(885) can be used to perform pulse output without acceleration or
deceleration. Either independent mode positioning or continuous mode speed
control is possible. For independent mode positioning, the number of pulses is
set using PULS(886).
SPED(885) can also be executed during pulse output to change the output
frequency, creating stepwise changes in the speed.
Operand Contents
P Port specifier 0000 hex: Pulse output 0
0001 hex: Pulse output 1
T Pulse type 0000 hex: Relative pulse output
0001 hex: Absolute pulse output
N First number
of pulses word
N and N+1 contain the number of pulses setting. (N contains
the rightmost 4 digits and N+1 contains the leftmost 4 digits.)
Relative pulse output:
0000 0000 to 7FFF FFFF hex (0 to 2,147,483,647)
Absolute pulse output:
8000 0000 to 7FFF FFFF hex (-2,147,483,648 to
2,147,483,647)
PULS(886)
P
T
N
P: Port specifier
T: Pulse type
N: Number of pulses
Operand Contents
P Port specifier 0000 hex: Pulse output 0
0001 hex: Pulse output 1
TOutput
mode
Bits 0 to 3 Mode
0 hex: Continuous
1 hex: Independent
Bits 4 to 7 Direction
0 hex: CW
1 hex: CCW
Bits 8 to 11 Pulse output method (See note.)
0 hex: CW/CCW
1 hex: Pulse + direction
Bits 12 to 15 Not used. (Always 0 hex.)
F First pulse frequency
word
F and F+1 contain the pulse frequency setting, in units of
1 Hz. (F contains the rightmost 4 digits and F+1 contains
the leftmost 4 digits.)
0000 0000 to 0001 86A0 hex (0 Hz to 100 kHz)
J models: 0000 0000 to 0000 4E20 hex (0Hz to 20kHz)
SPED(885)
P
T
F
P: Port specifier
T: Output mode
F: First pulse frequency word
