Pulse Outputs Section 5-2
Combinations of
Pulse Control
Instructions
The following tables show when a second pulse control instruction can be
started if a pulse control operation is already being executed.
Generally, a second independent-mode positioning instruction can be started
if an independent-mode positioning instruction is being execute, and a second
continuous-mode speed control instruction can be started if a continuous-
mode speed control instruction is being executed. Operation cannot be
switched between the independent and continuous modes, although
PLS2(887) can be started while ACC(888) (continuous mode) is being exe-
cuted.
It is possible to start another operation during acceleration/deceleration and
start another positioning instruction during positioning.
Note (1) SPED(885) (Independent) to SPED(885) (Independent)
Operand Contents
P Port specifier 0000 hex: Pulse output 0 (duty factor set in 1% units, fre-
quency 0.1 Hz units)
0001 hex: Pulse output 1 (duty factor set in 1% units, fre-
quency 0.1 Hz units)
1000 hex: Pulse output 0 (duty factor set in 0.1% units,
frequency 0.1 Hz units)
1001 hex: Pulse output 1 (duty factor set in 0.1% units,
frequency 0.1 Hz units)
0100 hex: Pulse output 0 (duty factor set in 1% unit, fre-
quency 1 Hz units)
0101 hex: Pulse output 1 (duty factor set in 1% unit, fre-
quency 1 Hz units)
1100 hex: Pulse output 0 (duty factor set in 0.1% unit,
frequency 1 Hz units)
1101 hex: Pulse output 1 (duty factor set in 0.1% unit,
frequency 1 Hz units)
T Frequency 0001 to FFFF hex (0.1 to 6553.5 Hz, in 0.1 Hz units)
0001 to 8020 hex (1 to 32,800 Hz, in 1 Hz units)
S Duty factor Specify the duty factor of the pulse output, i.e., the percent-
age of time that the output is ON.
0000 to 03E8 hex: 0.0% to 100.0% (in 0.1 units)
0000 to 0064 hex: 0.0% to 100% (in 1% units)
Instruction being executed Starting instruction
(❍
: Can be executed., ×: Instruction Error occurs and Error Flag goes ON)
INI(880) SPED(885)
(Independent)
SPED(885)
(Continuous)
ACC(888)
(Independent)
ACC(888)
(Continuous)
PLS2(887) ORG(889)
SPED(885) (Independent) ❍❍ (note 1) × ❍ (note 3) ×××
SPED(885) (Continuous) ❍ × ❍ (note 2) × ❍ (note 5) ××
ACC(888)
(Independent)
Steady speed ❍ ××❍ (note 4) × ❍ (note 6) ×
Accelerating or
decelerating
❍ ××❍ (note 4) × ❍ (note 6) ×
ACC(888)
(Continuous)
Steady speed ❍ ×××❍ (note 5) ❍ (note 7) ×
Accelerating or
decelerating
❍ ×××❍ (note 5) ❍ (note 7) ×
PLS2(887) Steady speed ❍ ××❍ (note 4) × ❍ (note 8) ×
Accelerating or
decelerating
❍ ××❍ (note 4) × ❍ (note 8) ×
ORG(889) Steady speed ❍ ××××××
Accelerating or
decelerating
❍ ××××××
PWM ❍ ××××××
