602
Auxiliary Area Allocations by Function Appendix C
Name Description Read/Write Updated
Inverter Fre-
quency Com-
mand Value
This word contains the automatically calculated fre-
quency command value for the inverter.
Data range: 0000 to FFFF hex (0.00 to 655.35 Hz) (0.01-
Hz increments, unsigned)
Set the Power Supply Frequency for One Motor Revolu-
tion per Second, Number of Encoder Pulses for One
Motor Revolution, and Error Counter Cycle in the PLC
Setup before using this value.
Read Cleared when power is turned ON.
Cleared when operation starts.
Cleared when an error occurs in
the error counter.
Updated each error counter cycle.
Present Value of
Unsigned Output
Value
These words contain the present value of the unsigned
output value (output value = present value of error
counter × error counter cycle (s) × gain).
Data range: 0000 0000 to 8000 0000 hex
(0 to 2,147,483,648)
The maximum and minimum output values are applied.
Read Cleared when power is turned ON.
Cleared when operation starts.
Cleared when an error occurs in
the error counter.
Updated each error counter cycle.
Present Value of
Signed Output
Value
These words contain the present value of the signed out-
put value (output value = present value of error counter ×
error counter cycle (s) × gain).
Data range: 8000 0000 to 7FFF FFFF hex
(214,748,348 to 214,748,347)
The maximum and minimum output values are applied.
Read Cleared when power is turned ON.
Cleared when operation starts.
Cleared when an error occurs in
the error counter.
Updated each error counter cycle.
Operation Com-
mand Flag
This flag turns ON during an inverter positioning opera-
tion command.
ON: Operation command executed.
OFF: Stop command executed.
Read Turned OFF when power is turned
ON.
Turned OFF when operation starts.
Turned OFF when CPU Unit opera-
tion stops.
Turned OFF when inverter posi-
tioning is stopped (immediate stop)
using INI instruction.
Forward Operation
Command Flag
This flag turns ON during an inverter positioning forward
operation command.
ON: Forward command in progress
OFF: Reverse command in progress or stopped
Read Turned OFF when power is turned
ON.
Turned OFF when CPU Unit opera-
tion starts.
Turned OFF when CPU Unit opera-
tion stops.
Turned OFF when error counter
present value is 0 or less than 0
(negative).
Turned ON when error counter
present value is greater than 0
(positive).
Reverse Opera-
tion Command
Flag
This flag turns ON during an inverter positioning reverse
operation command.
ON: Reverse command in progress
OFF: Forward command in progress or stopped
Read Turned OFF when power is turned
ON.
Turned OFF when CPU Unit opera-
tion starts.
Turned OFF when CPU Unit opera-
tion stops.
Turned OFF when error counter
present value is 0 or greater than 0
(positive).
Turned ON when error counter
present value is less than 0 (nega-
tive).
In-position Flag This flag turns ON when inverter positioning is in position.
ON: In position
OFF: Not in position
Read Turned OFF when power is turned
ON.
Turned OFF when CPU Unit opera-
tion starts.
Turned OFF when CPU Unit opera-
tion stops.
Turned OFF when pulses are being
output to error counter.
Turned OFF absolute value of error
counter present value is greater
than in-position range.
Turned OFF when pulse output to
error counter is stopped and abso-
lute value of error counter present
value is less than in-position range
