Omron CQM1H - PROGRAM

219
Instruction Tables Section 5-7
ADDL (@) 54 4 DOUBLE BCD ADD 323
AND None 1 AND 222
AND LD None 1 AND LOAD 223
AND NOT None 1 AND NOT 222
ANDW (@) 34 4 LOGICAL AND 373
APR (@) –– 4 ARITHMETIC PROCESS 344
ASC (@) 86 4 ASCII CONVERT 301
ASFT(@) 17 4 ASYNCHRONOUS SHIFT REGISTER 268
ASIN (@) –– 3 ARC SINE 365
ASL (@) 25 2 ARITHMETIC SHIFT LEFT 263
ASR (@) 26 2 ARITHMETIC SHIFT RIGHT 263
ATAN (@) –– 3 ARC TANGENT 367
AVG –– 4 AVERAGE VALUE 341
BCD (@) 24 3 BINARY TO BCD 292
BCDL (@) 59 3 DOUBLE BINARY-TO-DOUBLE BCD 293
BCMP (@) 68 4 BLOCK COMPARE 283
BCNT (@) 67 4 BIT COUNTER 385
BIN (@) 23 3 BCD-TO-BINARY 291
BINL (@) 58 3 DOUBLE BCD-TO-DOUBLE BINARY 293
BSET (@) 71 4 BLOCK SET 272
CLC (@) 41 1 CLEAR CARRY 317
CMND (@) –– 4 DELIVER COMMAND 412
CMP 20 3 COMPARE 280
CMPL 60 4 DOUBLE COMPARE 284
CNT None 2 COUNTER 235
CNTR 12 3 REVERSIBLE COUNTER 237
COLL (@) 81 4 DATA COLLECT 275
COLM(@) –– 4 LINE TO COLUMN 314
COM (@) 29 2 COMPLEMENT 372
COS (@) –– 3 COSINE 363
CPS –– 4 SIGNED BINARY COMPARE 286
CPSL –– 4 DOUBLE SIGNED BINARY COMPARE 287
CTBL(@) 63 4 COMPARISON TABLE LOAD 243
DBS (@) –– 4 SIGNED BINARY DIVIDE 336
DBSL (@) –– 4 DOUBLE SIGNED BINARY DIVIDE 337
DEC (@) 39 2 BCD DECREMENT 376
DEG (@) –– 3 RADIANS TO DEGREES 361
DIFD 14 2 DIFFERENTIATE DOWN 226
DIFU 13 2 DIFFERENTIATE UP 226
DIST (@) 80 4 SINGLE WORD DISTRIBUTE 273
DIV (@) 33 4 BCD DIVIDE 321
DIVL (@) 57 4 DOUBLE BCD DIVIDE 326
DMPX (@) 77 4 16-TO-4 ENCODER 296
DSW 87 4 DIGITAL SWITCH 427
DVB (@) 53 4 BINARY DIVIDE 331
END 01 1 END 227
EXP (@) –– 4 EXPONENT 370
FAL (@) 06 2 FAILURE ALARM AND RESET 230
FALS 07 2 SEVERE FAILURE ALARM 230
Mnemonic Code Words Name Page
