Omron CQM1H - PROGRAM User Manual

293
Conversion Instructions Section 5-20
5-20-3 DOUBLE BCD-TO-DOUBLE BINARY – BINL(58)
Limitations DM 6143 to DM 6655 cannot be used for R.
Precautions When the execution condition is OFF, BINL(58) is not executed. When the
execution condition is ON, BINL(58) converts an eight-digit number in S and
S+1 into 32-bit binary data, and outputs the converted data to R and R+1.
Flags ER: The contents of S and/or S+1 words are not BCD.
Indirectly addressed EM/DM word is non-existent.
(Content of *EM/*DM word is not BCD, or the EM/DM area boundary
has been exceeded.)
EQ: ON when the result is zero.
5-20-4 DOUBLE BINARY-TO-DOUBLE BCD – BCDL(59)
Limitations If the content of S exceeds 05F5E0FF, the converted result would exceed
99999999 and BCDL(59) will not be executed. When the instruction is not
executed, the content of R and R+1 remain unchanged.
DM 6143 to DM 6655 cannot be used for R.
Description BCDL(59) converts the 32-bit binary content of S and S+1 into eight digits of
BCD data, and outputs the converted data to R and R+1.
S: First source word (BCD)
IR, SR, AR, DM, EM, HR, TIM/CNT, LR
R: First result word
IR, SR, AR, DM, EM, HR, LR
Ladder Symbols Operand Data Areas
BINL(58)
S
R
@BINL(58)
S
R
S + 1 S
R + 1 R
BCD
Binary
S: First source word (binary)
IR, SR, AR, DM, EM, HR, LR
R: First result word
IR, SR, AR, DM, EM, HR, LR
Ladder Symbols Operand Data Areas
BCDL(59)
S
R
@BCDL(59)
S
R
S + 1 S
R + 1 R
BCD
Binary

Omron CQM1H - PROGRAM Specifications

General

I/O Capacity	Up to 512 points
Power Supply	100 to 240 VAC, 50/60 Hz or 24 VDC (depending on model)
Instruction Set	Basic and advanced instructions
Operating Temperature	0 to 55°C
Program Capacity	7.2K to 15.2K steps
Communication Ports	RS-232C
Expansion Slots	Up to 3 expansion units
Type	Programmable Logic Controller (PLC)
CPU Type	RISC
Program Memory	7.2K to 15.2K steps
I/O Points	512 max
Expansion Capability	Up to 3 expansion units
Data Memory	RAM (battery backup)
