Omron CQM1H - PROGRAM - 32-Bit to Floating: Fltl; Floating-Point Add: +F

355
Floating-point Math Instructions Section 5-24
5-24-4 32-BIT TO FLOATING: FLTL(––)
Limitations The result will not be exact if a number with an absolute value greater than
16,777,215 (the maximum value that can be expressed in 24-bits) is con-
verted.
DM 6143 to DM 6655 cannot be used for R.
Description When the execution condition is OFF, FLTL(––) is not executed. When the
execution condition is ON, FLTL(––) converts the 32-bit signed binary value in
S+1 and S to 32-bit floating-point data (IEEE754-format) and places the result
in R+1 and R. A single 0 is added after the decimal point in the floating-point
result.
Signed binary data within the range of –2,147,483,648 to 2,147,483,647 can
be specified for S+1 and S. The floating point value has 24 significant binary
digits (bits). The result will not be exact if a number greater than 16,777,215
(the maximum value that can be expressed in 24-bits) is converted by
FLTL(––).
Example Conversions:
A signed binary value of 16,777,215 is converted to 16,777,215.0.
A signed binary value of –16,777,215 is converted to –16,777,215.0.
Flags ER: Indirectly addressed EM/DM word is non-existent.
(Content of *EM/*DM word is not BCD, or the EM/DM area boundary
has been exceeded.)
EQ: ON if both the exponent and mantissa of the result are 0.
5-24-5 FLOATING-POINT ADD: +F(––)
S: First source word
IR, SR, AR, DM, EM, HR, TIM/CNT, LR
R: First result word
IR, SR, AR, DM, EM, HR, LR
Ladder Symbols
Operand Data Areas
Third operand: Always 000
−−−
FLTL(−− )
S
R
000
@FLTL(−− )
S
R
000
R+1 R
S
Floating-point data (32 bits)
Signed binary data (32 bits
)
S+1
Au: First augend word
IR, SR, AR, DM, EM, HR, TIM/CNT, LR
Ad: First addend word
IR, SR, AR, DM, EM, HR, TIM/CNT, LR
Ladder Symbols
Operand Data Areas
R: First result word
IR, SR, AR, DM, EM, HR, LR
+F(−− )
Au
Ad
R
@+F(−− )
Au
Ad
R
