Timer and Counter Instructions Section 5-16
Stop Pulse Output If C is 003, INI(61) stops pulse output. Refer to 1-5 Pulse Output Function for
details on stopping Pulse I/O Board pulse outputs 1 and 2.
Note Pulse output can be stopped only when pulses are not currently being output.
The Pulse Output Flag (AR 0515 or AR 0615) can be used to check pulse out-
put status.
Flags ER: The specified port and function are not compatible.
Indirectly addressed EM/DM word is non-existent.
(Content of *EM/*DM word is not BCD, or the EM/DM area boundary
has been exceeded.)
P1+1 exceeds the data area boundary. (C=002)
There is an error in the operand settings.
INI(61) is executed in an interrupt subroutine while a pulse I/O or
high-speed counter instruction is being executed in the main program.
5-16-9 HIGH-SPEED COUNTER PV READ – PRV(62)
Limitations ID and D+1 must be in the same data area.
DM 6143 to DM 6655 cannot be used for D.
Description PRV(62) can be used with the functions listed in the following table.
When the execution condition is OFF, PRV(62) is not executed. When the exe-
cution condition is ON, PRV(62) reads data specified by P and C and writes it
to D or D and D+1.
The port specifier (P) specifies the high-speed counter or pulse output that
will be controlled.
P: Port specifier
000 to 004 or 101 to 104
Ladder Symbols Operand Data Areas
@PRV(62)
P
C
D
D: First destination word
IR, SR, AR, DM, EM, HR, LR
C: Control data
000 to 004 or 101 to 104
PRV(62)
P
C
D
Unit/Board Function
CPU Unit High-speed counter 0 (IR 00004 to IR 00006)
Pulse I/O Board High-speed counters 1 and 2
Pulse outputs 1 and 2
Absolute Encoder Interface Board Absolute high-speed counters 1 and 2
High-speed Counter Board High-speed counters 1 to 4
Unit Function Port specifier (P)
CPU Unit High-speed counter 0 000
Transistor Output Unit Pulse output 000
