Omron CQM1H - PROGRAM User Manual

468
Host Link Commands Section 6-5
Response Format An end code of 00 indicates normal completion.
Parameters Model Code
“Model code” indicates the PC model in two digits hexadecimal.
6-5-31 TEST–– TS
Returns, unaltered, one block of data transmitted from the host computer.
Command Format
Response Format An end code of 00 indicates normal completion.
Parameters Characters (Command, Response)
For the command, this setting specifies any characters other than the carriage
return (CHR$(13)). For the response, the same characters as specified by the
command will be returned unaltered if the test is successful.
@ MMx 10
0
x 10
1
x 16
1
x 16
0
↵
*
x 16
1
x 16
0
Node
No.
Header
code
TerminatorFCSEnd code Model
code
Model code Model
01 C250
02 C500
03 C120
0E C2000
10 C1000H
11 CQM1H/C2000H/CQM1/CPM1/CPM1A/CPM2A/CPM2C/SRM1
12 C20H/C28H/C40H/C200H/C200HS
20 CV500
21 CV1000
22 CV2000
40 CVM1-CPU01-E
41 CVM1-CPU11-E
42 CVM1-CPU21-E
@ TSx 10
0
x 10
1
*
↵
Node No. Header
code
Characters
122 characters max.
TerminatorFCS
@ TSx 10
0
x 10
1
*
↵
Node No. Header
code
Characters
122 characters max.
TerminatorFCS

Omron CQM1H - PROGRAM Specifications

General

I/O Capacity	Up to 512 points
Power Supply	100 to 240 VAC, 50/60 Hz or 24 VDC (depending on model)
Instruction Set	Basic and advanced instructions
Operating Temperature	0 to 55°C
Program Capacity	7.2K to 15.2K steps
Communication Ports	RS-232C
Expansion Slots	Up to 3 expansion units
Type	Programmable Logic Controller (PLC)
CPU Type	RISC
Program Memory	7.2K to 15.2K steps
I/O Points	512 max
Expansion Capability	Up to 3 expansion units
Data Memory	RAM (battery backup)
