50
Communications Functions Section 1-6
Transmission Frame Format
Baud Rate
Transmission Delay Time
(DM 6647 and DM 6652)
Depending on the devices connected to the communications port, it may be
necessary to allow time for transmission. When that is the case, set the trans-
mission delay to regulate the amount of time allowed.
The transmission delay is set in the PC Setup to create a minimum interval
between sending data from the PC. The transmission delay is used for the fol-
lowing serial communications modes.
The delay is not used the first time data is sent from the PC. The delay will
affect other sends only if the normal time for the send comes before the time
set for the transmission delay has expired.
If the delay time has already expired when the next send is ready, the data will
be spent immediately. If the delay time has not expired, the send will be
delayed until the time set for the transmission delay has expired.
Setting Stop bits Data length Stop bits Parity
00171Even
01171Odd
02171None
03172Even
04172Odd
05172None
06181Even
07181Odd
08181None
09182Even
10182Odd
11182None
Setting Baud rate
00 1,200 bps
01 2,400 bps
02 4,800 bps
03 9,600 bps
04 19,200 bps
Serial communications
mode
Application
Host Link, responses Once the PC has sent a response to the host com-
puter, it will not send the next response until the time
set for the transmission delay has expired.
Host Link, PC-initiated com-
munications
Once the PC has sent data using TXD(48), it will not
send data again until the time set for the transmission
delay has expired.
No-protocol communications
15 0
Bit
Transmission delay (4 digits BCD; unit: 10 ms)
Default: No delay
DM 6647: RS-232C port
DM 6652: Peripheral port
