Tag name Description Set value
<node>
(Node No.)
The node No.
for the link.
1 to 62. An error will be generated if an out-of-range
value is set when a file is loaded.
<cpu>
(PLC type)
The PLC type
for the node.
CS1G, CS1G-H, CS1H, CS1H-H, CJ1G, CJ1G-H,
CJ1H-H, CJ1M, CS1D-H, CS1D-S, CV500, CV1000,
CV2000, CVM1, CVM1-V2, CQM1H, C200HE,
C200HE-Z, C200HG, C200HG-Z, C200HX, C200HX-Z,
NSB, CS/CJ/CP
<cpu-type>
(CPU model)
The CPU model
for the node.
CS1G: CPU42, CPU43, CPU44, CPU45
CS1G-H: CPU42, CPU43, CPU44, CPU45
CS1H: CPU63, CPU64, CPU65, CPU66, CPU67
CS1H-H: CPU63, CPU64, CPU65, CPU66, CPU67
CS1G/CJ1G: CPU44, CPU45
CJ1G-H: CPU42, CPU43, CPU44, CPU45
CJ1H-H: CPU65, CPU66, CPU67
CJ1M, CP1H: Not specified.
CS1D-H: CPU65, CPU67
CS1D-S: CPU42, CPU44, CPU65, CPU67
CV500: Not specified.
CV1000: Not specified.
CV2000: Not specified.
CVM1: CPU01, CPU11, CPU21
CVM1-V2: Not specified.
CQM1H: CPU51, CPU61
C200HE: Not specified.
C200HE-Z: Not specified.
C200HG: Not specified.
C200HG-Z: Not specified.
C200HX: Not specified.
C200HX-Z: Not specified.
C200HX-Z: CPU65, CPU85
NSB: Not specified.
<status-start-type>
(Status start address,
memory area)
The status start
address and the
memory area.
Any of the following memory areas can be specified,
regardless of the PLC type.
Initial value: Default (See note.)
CIO: Blank, CIO, or IR
DM: D or DM
LR: L or LR
EM: E + Bank No.
HR: H or HR
AR: A or AR
T/C: T/C
Note: Data link status is stored in the default area. For
details, refer to the Unit's operation manual.
(2) <node-param>
<status-start-ch>
(Status area start
address)
The start
address for the
status area.
The range differs depending on the status area type.
