PART 1: CX-Programmer
CHAPTER 1 – Technical Specifications OMRON
CX-Programmer _Page 2
♦ Upload/Download – The Upload/Download functionality has been updated to include the CV/CVM1,
CS1/CJ1, CJ1H/H-H and CS1G/H-H PLCs to avoid searching section markers on the initial dialog Upload.
♦ The range of the Send/Recv instruction has been extended to include the PLCs CS1/CJ1, CS1G/H-H and
CJ1G/H-H
♦ Operation – The levels of operation have been extended to include Junior, Demo and Trial versions of the
product.
♦ Symbol Sorting – The symbol sort for number data types has been enhanced and is now sorted separately
from other data types in the symbol table view.
♦ Direct import file range extended to include CPT, SP1 and COD files.
Version 3.0 of CX-Programmer offers the following enhancements.
♦ Support for new PLCs – Full support has been added for the, CJ1M, and CS1D series PLCs.
♦ Changed the sizes and positions of dialogs for editing Contact/Coil/Instruction, Find and Replace, and
Commented Rung.
♦ Auto Online, Work Online Simulator - Enhanced the online functionality making it easier to connect to
PLCs and debug programs.
♦ Combine and Split rungs - The combine and split functions have been added making it easy to add and
divide rungs.
♦ Watch Window - The watch window has been enhanced to enable addresses to be entered directly on the
watch sheet.
♦ Key Mapping - The data of Keyboard Mapping can be saved to a file (*.mac) and loaded into a CX-
Programmer.
♦ Section/Rung Manager - A function to edit a structure of Program is supported. Sections, Rungs and
comments can be edited on this dialog.
♦ I/O Comment view - A View to edit comments of addresses is now supported.
CX-Programmer supports the following PLCs.
Series Model CPU Types
CP1H X, XA
CP1L M, L
CP-Series
CP1E E, N, NA
CJ-Series CJ1G CPU 44, CPU 45
CJ-Series CJ1G-H CPU 42, CPU 43, CPU 44, CPU 45
CJ2H CPU 64, CPU 65, CPU 66, CPU 67, CPU 68,
CPU64-EIP, CPU65-EIP, CPU66-EIP, CPU67-EIP, CPU68-EIP
CJ-Series
CJ2M CPU11, CPU12, CPU13, CPU14, CPU15, CPU31, CPU32, CPU33,
CPU34, CPU35
CJ-Series CJ1H-H CPU64-R, CPU65-R, CPU66-R, CPU67-R, CPU 65, CPU 66, CPU 67
CJ-Series CJ1M CPU 11, CPU 12, CPU 13, CPU 21, CPU 22, CPU 23
CS-Series CS1G
CS1G-H
CPU 42, CPU 43, CPU 44, CPU 45
CS-Series CS1H
CS1H-H
CPU 63, CPU 64, CPU 65, CPU 66, CPU 67
CS1D-H CPU 65, CPU 67 CS-Series
CS1D-S CPU 42, CPU 44, CPU 65, CPU 67
CV-Series CV1000 CPU 01
CV-Series CV2000 CPU 01
CV-Series CV500 CPU 01
CV-Series CVM1 CPU 01, CPU 11
CV-Series CVM1-V2 CPU 01, CPU 11, CPU 21
C-Series C1000H CPU 01
