PART 1: CX-Programmer
OMRON CHAPTER 1 – Technical Specifications
CX-Programmer _Page 3
Series Model CPU Types
C-Series C2000H CPU 01
C-Series C200H CPU 01, CPU 02, CPU 03, CPU 11, CPU 21, CPU 22, CPU 23, CPU 31
C-Series C200HE CPU 11, CPU 32, CPU 42
C-Series C200HE-Z CPU 11, CPU 32, CPU 42
C-Series C200HG CPU 33, CPU 43, CPU 53, CPU 63
C-Series C200HG-Z CPU 33, CPU 43, CPU 53, CPU 63
C-Series C200HS CPU 01, CPU 03, CPU 21, CPU 23, CPU 31, CPU 33
C-Series C200HX CPU 34, CPU 44, CPU 54, CPU 64
C-Series C200HX-Z CPU 34, CPU 44, CPU 54, CPU 64, CPU 65, CPU 85
C-Series CPM1
(CPM1A)
CPU 10, CPU 20, CPU 30, CPU 40
C-Series CPM2*
CPM2*-S*
–
C-Series CQM1 CPU 11, CPU 21, CPU 41, CPU 42, CPU 43, CPU 44, CPU 45
C-Series CQM1H CPU 11, CPU 21, CPU 51, CPU 61
NSJ-Series NSJ G5D (Used for the NSJ5-TQ0*-G5D, NSJ5-SQ0*-G5D, NSJ8-TV0*-G5D,
NSJ10-TV0*-G5D, and NSJ12-TS0*-G5D)
FQM-CM FQM1-CM001/002
FQM-MMA FQM1-MMA21/22
FQM-Series
FQM-MMP FQM1-MMP21/22
IDSC – –
SRM1 SRM1 C01, C02
SRM1 SRM1-V2 C01, C02
Note: The CVM1-V1 PLC for types CPU01 and CPU11 cannot be specifically selected. Use the non
V2 types.
Refer to the CX-Server PLC Tools User Manual for information regarding available communication types.
System Requirements
System Requirements
Refer to the
CX-One Setup Manual
(Cat. No. W463) for the system requirements to install the CX-
Programmer on a computer.
Memory Capacity
The required RAM depends on the size of the programs that are created. For each Kstep of PLC
programming, approximately 2 Mbytes of available RAM is required. If more than one PLC is
registered in a project, the total RAM for the programs for all of the PLCs is required.
Examples:
Program size Recommended available memory
30 Ksteps or less 60 Mbytes min.
120 Ksteps or less 240 Mbytes min.
400 Ksteps or less 800 Mbytes min.
