368
Expansion TERMINAL Mode The
Programming Console can be put into Expansion TERMINAL
mode by turn
-
ing ON AR 0709. Pin 6 of the CPU’s DIP switch must be ON.
Switch
the Programming Console to Expansion
TERMINAL mode by turning AR 0709 ON.
PROGRAM BZ
<MESSAGE>
NO MESSAGE
PROGRAM BZ
CONSOLE
mode
T
urn AR 0709 OFF to return to CONSOLE mode.
7-1-18 Keyboard Mapping
The
C200HS supports the expansion keyboard mapping as well as normal
key
-
board
mapping. Expansion keyboard mapping controls the status of the 41 bits
SR
27700 through SR 27909, while normal keyboard mapping controls only
the
16
bits in AR 22. The status of these bits can be controlled by pressing the corre
-
sponding Programming Console keys when the Programming Console is in
TERMINAL mode or expansion TERMINAL mode.
The
following diagram shows how to
switch the Programming Console between
CONSOLE
mode (normal
operating mode) and TERMINAL or expansion TER
-
MINAL mode.
CONSOLE
mode
TERMINAL mode
(DIP switch pin 6 OFF)
Press the CHG key.
Press the CHG Key or
execute TERM(48).
T
urn OFF AR 0709
or turn OFF DIF switch pin 6.
T
urn ON AR 0709.
Expansion TERMINAL mode
(DIP switch pin 6 ON)
TERMINAL Mode The
Programming Console can be put into TERMINAL mode by pressing CHG
or
executing TERM(48) in the program.
Pin 6 of the CPU’
s DIP switch must be
OFF.
Press the CHG key again to return to CONSOLE mode.
When
the Programming Console is
in TERMINAL mode it can perform normal
keyboard mapping and display messages output by MSG(46) or LMSG(47).
With
keyboard mapping, bits 00 to 15 of AR 22 will be turned ON when keys 0 to
F are pressed on the Programming Console’s keyboard. A bit will remain ON
after the Programming Console’s key is released.
All
bits in AR 22 will be turned OFF when AR 0708 is turned ON. Keyboard map
-
ping inputs are disabled when AR 0708 is ON.
In addition to the keyboard mapping function, TERMINAL mode allows mes-
sages
output by MSG(46) and LMSG(47) to be displayed on the Programming
Console.
These messages will be erased if the Programming
Console is switch
back to CONSOLE mode.
Expansion TERMINAL Mode The
Programming Console can be put into Expansion TERMINAL
mode by turn
-
ing ON AR 0709. Pin 6 of the CPU’s DIP switch must be ON.
Turn
of
f AR 0709 or pin 6 of
the CPU’
s DIP switch to return to CONSOLE mode.
When
the Programming Console is
in TERMINAL mode it can perform expan
-
sion keyboard mapping and display messages output by MSG(46) or
LMSG(47). With expansion keyboard mapping, bits SR 27700 through
SR 27909
will be turned ON when the
corresponding key is pressed on the Pro
-
gramming
Console’
s keyboard. A bit will remain ON after the Programming Con
-
sole’s key is released.
Monitoring Operation and Modifying Data Section 7-1
