4.2.5 FINS client protocol
Trajexia can initiate the FINS communication using the FINS_COMMS
BASIC command. Refer to the command description for details.
Both the Read Memory (0101) and the Write Memory (0102) commands are
supported.
This functionality is useful to communicate with an OMRON PLC, another
Trajexia system or a PC running FINS server application software.
With the Read Memory command, memory can be read from other devices
with FINS server capability. The Write Memory command can be used to
write data to devices with FINS server capability.
The command returns one of the following values, depending on the
outcome of the execution:
/i
4.3 Serial protocol
The TJ1-MC__ TJ1-MC__ has a DB-9 connector that contains two serial
ports:
• Port 1: RS232
• Port 2: RS422 or RS485, depending on the switch settings
See the Trajexia Hardware Reference manual for details.
Both ports can independently support these protocols:
• Host Link master
• Host Link slave
• User defined protocol
4.3.1 Host Link master
If the TJ1-MC__ is the Host Link master, you can send BASIC commands to
a Host Link slave, for example a PC. When you send a BASIC command to
a Host Link slave, the execution of the next BASIC command waits until the
Host Link slave sends a response.
You can use these BASIC commands:
/i
Condition Response code
(hex)
Description
All elements valid 0000 OK
Var_type invalid 1101 No area type
Start_address invalid 1103 Address range designation error
Bit_number invalid 1103 Address range designation error
Number of elements invalid
(totals)
1104 Address out of range
-1 The command executed successfully.
0 The command failed.
1 Request was not sent because the client or the FINS protocol is busy.
2 One or more of the request parameters is invalid.
3 Invalid source memory area.
4 Request was sent, but no response from the remote server was received within the
timeout period.
5 An error response code was received from the remote server.
Note
The serial port (port 1) CANNOT be used for program-
ming the unit.
BASIC command Description
HLM_COMMAND HLM_COMMAND executes a specific Host Link command to the
slave.
