BASIC commands
PROGRAMMING MANUAL 66
Revision 3.0
/i
Example DEVICENET (0,2,1,10,16,150,31)
In this example, the TJ1-DRT is configured to exchange data with DeviceNet
master with 16 output words (received from the master) located at VR(10) to
VR(25), and 31 input words (sent to the master) located at VR(150) to
VR(180).
See also N/A
Bit Value Description
00 DEVICENET (unit_number, 2, ...) not executed yet
1 DEVICENET (unit_number, 2, ...) executed without error
1 0 No DeviceNet I/O connection
1 DeviceNet I/O connection running
2 0 VR variables in the output data range have been updated
1 VR variables in the output data range have not been updated yet
3 0 DeviceNet I/O connection size matches the DEVICENET
(unit_number, 2,…) command
1 DeviceNet I/O connection size does not match the
DEVICENET(unit_number, 2,…) command
4-7 0 Always zero
8 0 Network power OK
1 Network power failure
9 0 No BUSOFF occurred
1 BUSOFF occurred
10 0 No node address duplication error
1 Node address duplication error
I52E-EN-03.book Seite 66 Freitag, 29. Juni 2007 11:55 11
