5.4.3 Toolbar
/i
Connect Connects the Trajexia Tools to the Trajexia
system. Refer to Connect in "Controller
menu" (p. 198).
Disconnect Disconnects the Trajexia Tools from the Tra-
jexia system. Refer to Disconnect in the
menu "Controller menu" (p. 198).
Terminal Command line editor. Refer to Terminal in
the "Tools menu" (p. 205).
Axis
Parameters
Refer to Axis parameters in the "Tools menu"
(p. 205).
Intelligent
drives
Refer to Intelligent drives in the "Tools menu"
(p. 205).
Oscilloscope The software oscilloscope can be used to
trace axis and motion parameters. This
helps to program development and system
commissioning. Refer to oscilloscope in the
"Tools menu" (p. 205).
Keypad Not implemented in Trajexia.
Jog Axis This window allows the user to manually
move the axes on the Trajexia. Refer to Jog
Axis in the "Tools menu" (p. 205).
Digital IO Refer to Digital IO Status in the "Tools menu"
(p. 205).
Analog input Refer to Analog input in the "Tools menu"
(p. 205).
TABLE
values
Refer to the TABLE and VR values in the
"Tools menu" (p. 205).
VR values. Refer to the TABLE and VR values in the
"Tools menu" (p. 205).
Watch
variables
Not implemented in Trajexia.
Simulator Not fully implemented in Trajexia.
Trajexia
Tools Help
Opens Trajexia Tools Help.
Trio BASIC
Help
Opens Trio BASIC Help.
