Omron TJ1-MC04 - PROGRAMMING 1 User Manual

Examples and tips
PROGRAMMING MANUAL 289
Revision 3.0
6.2.5 Position on a grid
fig. 53
A square palette has sides 1m long. It is divided into a 5 x 5 grid,
and each of the positions on the grid contains a box which must be
filled using the same square pattern of 100mm by 100mm. A
dispensing nozzle controlled by digital output 8 must be turned on
when filling the box and off at all other times.
I52E-EN-03.book Seite 289 Freitag, 29. Juni 2007 11:55 11
