Troubleshooting
PROGRAMMING MANUAL 305
Revision 3.0
7.6 TJ1-FL02
7.6.1 System errors
/i
Note:
After removing the cause of an error, make sure to re-ini-
tialise the MECHATROLINK-II bus on the unit on which
the error appeared. Type in the Trajexia Tools terminal
window:
MECHATROLINK(n, 0)
where n is the number of the unit to which the unit that
caused the error is connected.
Indication Problem Solution
All LEDs are off The power is off. Turn the power on.
The TJ1-FL02 is defective. Replace the TJ1-FL02.
RUN LED is on,
A EN or B EN LED
is off
The axis for which EN LED is
off is not enabled.
Enable the axis: perform
WDOG=ON and/or AXIS_ENABLE
on the axis.
RUN LED is on,
A EN or B EN LED
flashes
There is an axis error for the
axis for which EN LED flashes.
The TJ1-MC__ indicates the
number of the axis with an axis
error. Remove the cause of the axis
error, and clear the axis error or
restart the system.
I52E-EN-03.book Seite 305 Freitag, 29. Juni 2007 11:55 11
