Communication protocols
PROGRAMMING MANUAL 162
Revision 3.0
Timeout
The timeout mechanism is implemented to prevent that the BASIC task
pauses for a long time due to bad or no communication. The
HLM_TIMEOUT parameter specifies the timeout period. This period is the
maximum time the program task waits after it has sent the command to
receive a response.
If the timeout period elapses, the HLM_STATUS contains the status of the
command, and the BASIC task continues.
The HLM_TIMEOUT parameter specifies the timeout period for all
commands and for all ports.
Status
The HLM_STATUS parameter contains the status of the last Host Link
master command sent to the specified port. The parameter indicates the
status for the HLM_READ, HLM_WRITE and HLM_COMMAND
commands. The status bits are:
/i
The HLM_STATUS has value 0 when no problems occurred. In case of a
non-zero value you need to program an appropriate action such as a retry or
emergency stop in the user BASIC program. Each port has an
HLM_STATUS parameter. You need the PORT modifier to specify the port.
Examples
In these examples we assume this set-up:
• A Trajexia system with a TJ1-MC__.
• A slave PC, with node address 13.
• A connection from the serial port of the TJ1-MC__ to the PC. The serial
port uses RS422 communication.
/i
/i
Bit Name Description
0-7 End code The end code is:
• the end code defined by the Host Link slave, when a prob-
lem occurred in the data string of the sent command, or
• an end code defined by the Host Link master, when a prob-
lem occurred in the data string of the received response.
8 Timeout error A timeout error occurs if no response is received within the time-
out period. This indicates that the communication is lost.
9 Command not
recognised
This status indicates that the slave did not recognise the com-
mand and has returned an IC response.
Example Reading data from the PC using HLM_READ.
BASIC code ' Set up Host Link master for port 2
SETCOM(9600,7,2,2,2,6)
' Source address: CIO/IR 002
' Amount of data: 2 words
' Destination address: VR(0)
HLM_READ(2,13,PLC_IR,2,2,MC_VR,0)
Host Link
communication
• From Host Link master to Host Link slave:
@13RR0002000242*
• From Host Link slave to Host Link master:
@13RR000101010241*
Result • VR address = 0: value = 257.0000
• VR address = 1: value = 258.0000
Example Writing data to the PC using HLM_WRITE.
BASIC code ' Source address: TABLE(18)
' Amount of data: 2 words
' Destination address: LR 014
TABLE(18,$0701,$0702)
HLM_WRITE(2,13,PLC_LR,14,2,MC_TABLE,18)
Host Link
communication
• From Host Link master to Host Link slave:
@13WL0014070107025F*
• From Host Link slave to Host Link master:
@13WL0059*
Result • LR address = 0: value = 701 (hex)
• LR address = 1: value = 702 (hex)
