Panasonic KX-TDA50

1.20 Portable Station (PS) Features
Feature Guide 161
alleviates this strain on the CS because only one channel is needed to ring a PS ring group's members.
PS ring group members and related parameters are assigned through system programming, as explained
below.
a) Floating Extension Number: When this number is called, all PSs in the group ring.
b) Group Name: Can be displayed on a ringing PS to indicate that the incoming CO line call is a
group call, and not a call directed to the PS's extension number. This is only available when
Incoming CO Line Call Information Display is set to "Called Number".
c) Incoming CO Line Call Information Display: Determines which information is shown on the PS
display when a group call is received. Select "Caller ID" to display the caller's telephone number
or name, or "Called Number" to display the name of the PS ring group which is receiving the call.
d) Member PSs: Select each PS that will be a member of the corresponding PS ring group. Note that
a PS can belong to more than one PS ring group.
[Programming Example: PS Ring Group]
[Example of PS Ring Groups 1 and 2]
Explanation:
PS Ring Group 1
PS 1, PS 2, and PS 3 will ring simultaneously when a call is directed to floating extension number 301, and,
in the case of a CO line call, will display the Caller ID information for the call.
These PSs will ring individually when a call is directed to their assigned extension numbers (programming
not shown here).
Floating Extension No.
Group Name
Incoming CO Line
Information Display
PS Ring Group 1 PS Ring Group 2 PS Ring Group 3
PS 1
PS 2
PS 3
PS 4
PS 5
PS 6
PS 7
PS 8
301
Sales 1
Caller ID
302
Sales 2
Called Number
303
Customer Service
Caller ID
PS Ring Group Member
PS Ring Group 1
Floating Extension No. 301
Name: Sales 1
PS Ring Group 2
Floating Extension No. 302
Name: Sales 2
PS 1
Extn. 601
PS 2
Extn. 602
PS 3
Extn. 603
PS 4
Extn. 701
PS 5
Extn. 702
