4.3 Connect
290 Feature Guide
4.3 Connect
4.3.1 Connect—RS-232C
Connects to the PBX in Interactive mode through the serial RS-232C interface of the PBX.
The settings are as follows:
To connect using RS-232C
1.
From the Connect menu, select RS-232C.
2. Enter the settings as required.
3. Click OK.
4.3.2 Connect—USB
Connects to the PBX in Interactive mode through the USB port on the PBX, or a USB port (USB Module)
attached to a DPT.
To connect using USB
1.
From the Connect menu, select USB.
2. Enter the password corresponding to the Programmer Code used to log on to the Maintenance
Console.
3. Click OK.
Setting Values Description
Port COM1–COMx Specify the number of the COM port
assigned to the PC's RS-232C interface.
Only available COM ports will be
displayed.
NL Code CR, CR+LF Specify the code to be sent to signify the
end of a line. Choose CR+LF.
Baud Rate 2400bps, 4800bps,
9600bps, 19200bps,
38400bps, 57600bps,
115200bps
Specify the speed of data transmission.
Flow Control None, Hardware Specify whether the rate of data transfer
is managed by hardware or not. Choose
Hardware.
Password – Enter the password corresponding to the
Programmer Code used to log on to the
Maintenance Console.
