3.2 PC Programming
Feature Guide 251
3.2 PC Programming
3.2.1 Installing and Starting KX-TDA50 Maintenance Console
System programming, diagnosis, and data upload/download can be performed with a PC using the KX-
TDA50 Maintenance Console software.
This section briefly describes how to install and start KX-TDA50 Maintenance Console on a PC which is
connected to the PBX via USB.
System Requirements
Operating System
•Microsoft
®
Windows
®
98 SE, Windows Me, Windows 2000, or Windows XP
Hardware
• CPU: 133 MHz Intel
®
Pentium
®
or faster
• RAM: At least 64 MB of available RAM (128 MB recommended)
• Hard disk space: At least 100 MB
Installing KX-TDA50 Maintenance Console
Notes
• Make sure to install and use the KX-TDA50 Maintenance Console for MPR version 2.0.
• To install or uninstall the software on a PC running Windows 2000 Professional or Windows XP
Professional, you must be logged in as a user which is in either the "Administrators" or "Power
Users" group.
• When the PBX is first connected to the PC via USB, a wizard should appear and ask you to select
the appropriate USB driver. Browse for and select the KX-TDA USB driver, which is copied to the
local drive during installation.
Starting KX-TDA50 Maintenance Console
Note
The screenshots shown here are for reference only, and may differ from the screens displayed on your
PC.
1. Copy the KX-TDA50 Maintenance Console setup file to a local drive on the PC.
(Its icon is shown here, on the left.)
2. Double-click the setup file to run the installer.
3. Follow the on-screen instructions provided by the installation wizard.
1. Connect the PC to the PBX with a USB cable.
2. Start KX-TDA50 Maintenance Console from the Start
menu.
