4.5 Utility
302 Feature Guide
The items displayed on screen are as follows:
Note
For a list of common errors and solutions, see "4.1.5 Troubleshooting by Error Log" of the Installation
Manual.
To view the error log
•From the Utility menu, select Error Log.
4.5.8 Utility—CS Information
Displays information stored by the PBX regarding each Cell Station (CS).
This option is only available at Installer level, and requires that the target HLC, DHLC or DLC card be set to
INS status.
The displayed items are as follows:
Button Function
Cancel Closes the Error Log screen without saving.
Capture Saves the currently displayed Error Log information as a text file.
Minor Displays minor errors, which affect only a certain part of system
operation.
Major Displays major errors, which affect operation of the whole system,
or result in system failure.
Clear Erases the stored error log information from both the screen and
the PBX.
Item Description
Index The ordinal number assigned to an error record in the current log.
Date The date of the error detection.
Time The time of the error detection.
Error Code The 3-digit error code assigned by the PBX.
Sub Code The 5-digit sub code of the relevant hardware. (1XXYY)
1: Cabinet number
XX: Slot number
YY: Physical port number (01 to 16)
Error Message A description of the error.
Item Description
Slot Number of the slot
Port Number of the port
