4.5 Utility
Feature Guide 299
To transfer files to the SD memory card
1.
From the Utility menu, select File Transfer PC to PBX (SD Card).
The dialog box will be displayed.
2. Select the file to upload.
A window showing the upload progress will be displayed.
During transfer, the PBX automatically renames files transferred to the SD memory card according to
the header information.
A message will be displayed when the transfer is complete.
3. Click OK.
4.5.3 Utility—File Transfer PBX (SD Card) to PC
Copies system data files from the SD memory card installed in the PBX to the connected PC.
This option is only available at Installer level.
The files that can be downloaded from the SD memory card are as follows:
Downloading the DSSYS system data file allows you to make a backup of the configuration of the PBX.
The error data files are snapshots of the configuration of the PBX taken automatically when a major error
causes a system reset. They can be analyzed by your dealer to identify the source of a problem. If there is
only one error data file, its name will be $SYSERR. If there is more than one file, the files will be numbered
in chronological order, up to a maximum of 9 files.
Initial Data
Name on SD Memory Card Corresponding Card
DSINI MPR
DSIDHLC DHLC4
DSIHLC HLC4
DSIPLC PLC4/PLC8
DSISLCLC SLC4/SLC8
DSIDLC DLC4/DLC8
DSILCOT LCOT2/LCOT4
DSIEIO DPH4
DSIIPGW IP-GW4
File Type File Name
System Data DSSYS
Error Data $SYSERR
$SYSERR1–$SYSERR9
Feature Restriction DSKEYSD
