Panasonic KX-TDA50

4.7 Configuration [1]
316 Feature Guide
PLC4: 4-Port Proprietary Extension Card
SLC8: 8-Port Single Line Telephone Extension Card
SLC4: 4-Port Single Line Telephone Extension Card
LCOT4: 4-Port Analog Trunk Card
IP-GW4: 4-Channel VoIP Gateway Card
MSG2: 2-Channel Message Card
DPH4: 4-Port Doorphone Card
ECHO8: 8-Channel Echo Canceller Card
EXT-CID: Extension Caller ID Card
Maximum Quantity:
Extension card: 3 (1 in the Free Slots Type A; 2 in the Free Slots Type B)
Trunk card: 4 (3 in the Free Slots Type A; 1 in the Free Slots Type B)
MSG2 card: 2
DPH4 card: 1
ECHO8 card: 1
EXT-CID card: 1
Installation Manual References
1.3.1 Options
Programming References
4.7.3 Slot [1-1] Extension Card Property
4.7.4 Slot [1-1] LCO Card Property
4.7.5 Slot [1-1] IP-GW Card Property
4.7.6 Slot [1-1] DPH Card Property
Feature Guide References
None
Status
Indicates the status of the service card in each slot (reference only).
This column offers two ways to open the screen to select the card command:
• Click the desired cell in the column.
• Use the arrow key to select the desired cell in the column, and then click Command.
Default
Slot 00: - (fixed)
Other slots: Current status
Value Range
INS: The card is in service.
OUS: The card is out of service.
Fault: The card has been removed from the slot, or is not communicating with the PBX.
Fault-OVER: The number of CO line and/or extension ports exceed the system capacity.
