Panasonic KX-UTG200

Example
PANASIPPhoneConfig/Device/Lines/Line idx="n"/Sip
<PANASIPPhoneConfig>
<Device>
<Lines>
<Line idx="1">
<SIP>
<!-- Add per line sip settings here -->
</SIP>
</Line>
</Lines>
</Device>
</PANASIPPhoneConfig>
Example
<PANASIPPhoneConfig>
<Initial>
<Certs>
<CFG_ROOT_CERTIFICATE_PATH1></CFG_ROOT_CERTIFICATE_PATH1>
<CFG_ROOT_CERTIFICATE_PATH2></CFG_ROOT_CERTIFICATE_PATH2>
<CFG_ROOT_CERTIFICATE_PATH3></CFG_ROOT_CERTIFICATE_PATH3>
</Certs>
<CfgFiles>
<CFG_STANDARD_FILE_PATH>http://prov.com/Config{MAC}.cfg</CFG_STANDARD_FILE_PATH>
<CFG_PRODUCT_FILE_PATH>http:/prov.com/Config{MODEL}.cfg</CFG_PRODUCT_FILE_PATH>
<CFG_MASTER_FILE_PATH>http://prov.com/ConfigCom.cfg</CFG_MASTER_FILE_PATH>
</CfgFiles>
</Initial>
</PANASIPPhoneConfig>
The device configuration file contains all other parameters except <Certs> and <CfgFiles> parameters.
Example
<PANASIPPhoneConfig>
<Device>
<System>
<LoginAcc>
<ADMIN_ID>admin</ADMIN_ID>
<ADMIN_PASS>admin_pass</ADMIN_PASS>
</LoginAcc>
</System>
</Device>
</PANASIPPhoneConfig>
Note
• If the same parameter is specified in a same configuration file more than once, the last setting is
effective.
2.4.2 Flexible Enabling/Disabling of Parameters
Each parameter in the configuration file uses permission flags to indicate special manipulation of the parameter.
The following manipulations are supported.
1. Controlling enabling/disabling of parameters through web programming and phone programming
52 Administrator Guide Document Version 2015-01
2.4.2 Flexible Enabling/Disabling of Parameters
