Panasonic KX-UTG200

Phone Number
Description Indicates the currently assigned phone numbers (reference only).
Note
• The corresponding field is blank if a line has not yet been leased
or if the unit has not been configured.
Value Range Max. 32 digits
Default Value Not applicable.
Configuration File Reference PHONE_NUMBER (Page 338)
VoIP Status
Description Indicates the current VoIP status of each line (reference only).
Value Range
• Registered: The unit has been registered to the SIP server, and the
line can be used.
• Registering: The unit is being registered to the SIP server, and the
line cannot be used.
• Blank: The line has not been leased, the unit has not been
configured yet, or a SIP authentication failure has occurred.
• Register failed: The unit failed to register to the SIP server.
Note
• Immediately after starting up the unit, the phone numbers of the
lines will be displayed, but the status of the line may not be
displayed because the unit is still being registered to the SIP
server. To display the status, wait about 30 to 60 seconds, and
then click [Refresh] to obtain updated status information.
Default Value Not applicable.
Default Line
Description Indicates which line is the default line.
Value Range
• Blank
• V
Default Value Not applicable.
4.2.4 QoS Status
This screen allows you to view the current QoS status.
Document Version 2015-01 Administrator Guide 93
4.2.4 QoS Status
