Page 1-5
GENERAL DESCRIPTION
1
Names and Mechanism of Each Unit
Main units (Front view 2/2)
Board support blocks Board support
pins (option)
These are used to support the board.
Automatic mask cleaning
This unit cleans the back of the mask.
1E4C-AF00
1E4C-AE00
1B4C-180HC0AA00
1E4C-110HC1AA00
1E4C-101EC1AA00
1B4C-1956C2AE00
1E4C-E-OMA01-A01-00
Board flattening unit (option)
This unit prevents the board warp by
pressing down the board when it is
clamped.
Conveyor (Left/Right)
This conveyor transports boards in from
the previous process and out to the next
process.
1E4C-1956C2AA00 1B4C-1956C2AC00
1E4C-1956C2AD00
To Next Page
