Page 1-4
Main units (Front view 1/2)
Recognition unit & Squeegee driving unit
The recognition unit recognizes the
exchanged mask and the board recogni-
tion marks to correct the board position.
The squeegee driving unit drives squee-
gee.
X-Y table
This table moves the board positioning lift.
Board positioning lift
This unit positions boards and performs
the mask-release control at the printing
position.
1B4C-1955C0AA00
Names and Mechanism of Each Unit
1B4C-070MC0AA00
1B4C-160HC0AA00
1B4C-150VC0AA00
1E4C-AD00
1E4C-E-OMA01-A01-00
1E4C-AC00
1B4C-180GC1AA00
Squeegee head
This unit prints boards.
1B4C-070LC1AA00
To Next Page
