Philips Semiconductors Preliminary User Manual
LPC2119/2129/2194/2292/2294ARM-based Microcontroller
PIN DESCRIPTION FOR LPC2292/2294
Pin description for LPC2292/2294 and a brief of corresponding functions are shown in the following table.Pin Description
Table 56: Pin description for LPC2292/2294
Pin
Name
LQFP144
Pin #
Type Description
P0.0
to
P0.31
42,49,50,58,59
,61,68,69,75,7
6,78,83-
85,92,99,100,1
01,121-123,4-
6,8,21,23,25,3
2,33
I/O
Port 0: Port 0 is a 32-bit bi-directional I/O port with individual direction controls for each bit.
The operation of port 0 pins depends upon the pin function selected via the Pin Connect
Block. Pins 26 and 31 of Port 0 are not available.
Note: All Port 0 pins excluding those that can be used as A/D inputs (P0.27, P0.28, P0.29
and P0.30) are functionally 5V tolerant. If the A/D converter is not used at all, pins
associated with A/D inputs can be used as 5V tolerant digital IO pins. See "A/D Converter"
chapter for A/D input pin voltage considerations.
42 O
O
P0.0 TxD0 Transmitter output for UART0.
PWM1 Pulse Width Modulator output 1.
49
I
O
I
P0.1 RxD0 Receiver input for UART0.
PWM3 Pulse Width Modulator output 3.
EINT0 External interrupt 0 input.
50 I/O
I
P0.2 SCL I
2
C clock input/output. Open drain output (for I
2
C compliance).
CAP0.0 Capture input for TIMER0, channel 0.
58
I/O
O
I
P0.3 SDA I
2
C data input/output. Open drain output (for I
2
C compliance).
MAT0.0 Match output for TIMER0, channel 0.
EINT1 External interrupt 1 input.
59
I/O
I
P0.4 SCK0 Serial Clock for SPI0. SPI clock output from master or input to
slave.
CAP0.1 Capture input for TIMER0, channel 1.
61
I/O
O
P0.5 MISO0 Master In Slave Out for SPI0. Data input to SPI master or data
output from SPI slave.
MAT0.1 Match output for TIMER0, channel 1.
68
I/O
I
P0.6 MOSI0 Master Out Slave In for SPI0. Data output from SPI master or
data input to SPI slave.
CAP0.2 Capture input for TIMER0, channel 2.
69
I
O
I
P0.7 SSEL0 Slave Select for SPI0. Selects the SPI interface as a slave.
PWM2 Pulse Width Modulator output 2.
EINT2 External interrupt 2 input.
75
O
O
P0.8 TxD1 Transmitter output for UART1.
PWM4 Pulse Width Modulator output 4.
76
I
O
I
P0.9 RxD1 Receiver input for UART1.
PWM6 Pulse Width Modulator output 6.
EINT3 External interrupt 3 input.
