LPC2119/2129/2292/2294 Memory Addressing 51 May 03, 2004

Philips Semiconductors Preliminary User Manual

LPC2119/2129/2194/2292/2294ARM-based Microcontroller

Figure 5: VPB Peripheral Map

SPI0

(VPB peripheral #8)

0xE01F FFFF

0xE000 0000

0xE002 0000

TIMER0

(VPB peripheral #1)

Watchdog Timer

(VPB peripheral #0)

UART0

(VPB peripheral #3)

UART1

(VPB peripheral #4)

PWM0

(VPB peripheral #5)

not used

(VPB peripheral #6)

(VPB peripheral #7)

0xE001 C000

0xE001 8000

0xE001 4000

0xE001 0000

0xE000 C000

0xE000 8000

0xE000 4000

TIMER1

(VPB peripheral #2)

RTC

(VPB peripheral #9)

0xE002 4000

GPIO

(VPB peripheral #10)

0xE002 8000

Pin Connect Block

(VPB peripheral #11)

0xE002 C000

0xE003 0000

0xE003 4000

10 bit A/D

(VPB peripheral #13)

0xE003 8000

System Control Block

(VPB peripheral #127)

0xE01F C000

SPI1

(VPB peripheral #12)

(VPB peripherals #14-126)

not used
